SWIT K15 Field Monitor 15″

The SWIT K15 is a robust 15.4-inch on-camera monitor featuring a bright 1920×1200 FHD IPS panel with an impressive 1500nits luminance, guaranteeing exceptional visibility even in bright outdoor conditions. Experience deep blacks and superior image detail thanks to its enhanced contrast ratio. Built with a durable all-aluminum housing, rubber corner protection, and pre-installed screen protective glass, the K15 is designed to withstand demanding field use. The innovative Scene OS offers customizable workflows with quick access to essential tools, while automated color calibration via USB-C ensures accurate and consistent colors. With versatile mounting options and power solutions, the K15 is your reliable monitoring companion for any production.

What’s in the Box:
• 1 x SWIT K15 Field Monitor
• 1 x Screen Protective Glass (Pre-installed)
• 2 x Cheese Plates8
• 1 x VESA-to-C-stand Adaptor
• 1 x Carrying Case

Technical Specifications

Display:
• Panel Type: IPS, LED backlight
• Size: 15.4 inches (39.1 cm)
• Resolution: 1920 x 1200
• Aspect Ratio: 16:10
• Brightness: 1500 nits
• Contrast Ratio: 1650:1
• Color Depth: 10-bit14
• Viewing Angle: 178° (Horizontal) / 178° (Vertical)

Interfaces:
• SDI: 3G-SDI (2-in, 2-out)
• HDMI: HDMI 1.4
• USB: USB-A, USB-C
• Audio: 3.5mm audio output

Power:
• Power Input: AC 100-240V, DC XLR (11-17V), V-mount battery

Features:
• Sunlight-readable 1500nits brightness
• Durable all-aluminum housing
• Rubber corner protection
• Pre-installed screen protective glass
• Scene OS with 8 customizable scenes
• 8 tool shortcuts per scene
• Anamorphic de-squeeze
• Custom False color
• Zebra values
• Waveform | Vectors copes | Histogram
• Peaking | Focus assist | Crosshatch | Safe area markers
• SDI audio meters
• Timecode display
• Automatic 3DLUT color calibration via USB-C (X-rite CC Display Pro HL compatible)
• Interchangeable cheese plates (x2) with 6 mounting positions each
• VESA-to-C-stand adaptor

Physical:
• Dimensions: 387.4 mm x 280 mm x 90.7 mm
• Weight: 5.3 kg
• Working Temperature: 0°C ~ 40°C
